Electromagnetic Flowmeter
20000 INR
Product Details:
- Temperature Range 0C to 60C (ambient)
- Frequency 50/60 Hz
- Flow Rate 15-2000 LPM
- Resolution 0.001 m3/h
- Current Range 4-20 mA output
- Sensor Type Electromagnetic
- Measurement Range 0.03 to 12 m/s (velocity)
- Click to view more
X
Electromagnetic Flowmeter Price And Quantity
- 20000 INR
- 1 , , Piece
- 20000.00 - 40000.00 INR
- EEPROM memory retention
- 4-20 mA, Pulse Output, RS485
- Flow rate & Totalizer
- IP65 / IP68 (Optional)
- Modbus / HART (Optional)
- DN15 to DN600
- <0.5 seconds
- Powder coated aluminium
- Flanged
- SS316L / Hastelloy C / Titanium (Options)
- Electromagnetic Flowmeter
- 2 x M20 x 1.5
- IP65 Standard
- Flange as per ANSI B16.5 / DIN / JIS
- -10°C to 60°C
- PTFE / Hard Rubber
- ±0.2%
Electromagnetic Flowmeter Product Specifications
- 0C to 60C (ambient)
- 0.5% of reading
- Metal
- 50/60 Hz
- 15-2000 LPM
- 15-2000 LPM
- 0.001 m3/h
- <20VA
- 4-20 mA output
- Electromagnetic
- 0.03 to 12 m/s (velocity)
- 220V AC / 24V DC
- Up to 20,000 LPH (varies per model)
- 4-20 mA, RS485 Modbus
- 0-95%, non-condensing
- Analog And Digital
- Up to 16 bar
- EEPROM memory retention
- 4-20 mA, Pulse Output, RS485
- Flow rate & Totalizer
- IP65 / IP68 (Optional)
- Modbus / HART (Optional)
- DN15 to DN600
- <0.5 seconds
- Powder coated aluminium
- Flanged
- SS316L / Hastelloy C / Titanium (Options)
- Electromagnetic Flowmeter
- 2 x M20 x 1.5
- IP65 Standard
- Flange as per ANSI B16.5 / DIN / JIS
- -10°C to 60°C
- PTFE / Hard Rubber
- ±0.2%
Electromagnetic Flowmeter Trade Information
- 10 , , Piece Per Day
- Days
- Yes
- Sample costs shipping and taxes has to be paid by the buyer
- All India
Product Description
Backed by strong expertise and comprehension, we manufacture, export and supply only the best quality range of Electromagnetic Flow meter in the worldwide market. This flow meter is perfectly designed for the pipes with diameter of 10 mm to 600 mm. Widely used for corrosive as well aggressive range of conductive liquids, this Electromagnetic Flow meter find application in petrochemical, chemical and process industries.
Features
- Based on faradays law of electromagnetic induction
- Available in liner and electrode materials
- Excellent accuracy
Electromagnetic Flowmeter
Introduction :-
TORQUE series 6400 is new range of bipolar pulsed DC full bore type electromagnetic flow meters.It is suitable for pipes with diameter of 10 mm to 600 mm.they are based on faradays law of electromagnetic induction. The meter features flanged construction and is available with choice of liner and electrode materials. series 6400 has excellent accuracy and flow range ability the meter is suitable for use on wide range of corrosive and aggressive range of conductive liquids.
Application : -
- Chemical, petrochemical and Process Industries
- Fertilizer industries
- Sugar Industries
- Beverage Industries
- Pharmaceutical Industry
- Food Industry
- Drug Industries
- Paper and pulp Industries
- Aluminum Industries
- Steel Industries
- Mining Industries
- Dredging Industries
- Water and waste -water
- Management
- Water Supply Networks
- Chemical , Petrochemical and Process Industries
- Pharmaceutical Industries
- Waste Water management
- Sugar, Food , Drug and Beverages Industries
- Effluent Treatment Plants
- And Many Others
Other Information
- Pay Mode Terms: L/C (Letter of Credit), T/T (Bank Transfer
SPECIFICATION:-
|
Suitable for pipe sizes |
DN 10 to DN 2000 |
|
Media Conductivity (Min) |
10 S / cm (Consult factory for 5 S/cm) |
|
Media pressure |
PN 40 up to DN 80,PN 16 upto DN 200 & PN |
|
10 up to DN 600 |
|
|
Media Temperature (PTFE) |
0-180C with remote transmitter |
|
0-120C with integral transmitter |
|
|
0-90C max for other liners |
|
|
Material : Pipe |
SS 316 (NonMagnetic ) |
|
Liner |
PTFE / Neoprene / Polyurethane |
|
Electrode |
SS/ Hostelloy C / Ta / Ti / PL |
|
End Connection / Flanges |
Carbon steel / SS 304 / SS 316 / SS 316L |
|
Coil Housing |
Carbon steel / SS, Epoxy painted |
|
Transmitter |
Cast aluminum (LM6), Epoxy painted |
|
Power supply |
110 / 240 V AC + 15 %, 50 Hz |
|
Power consumption |
20 VA |
|
Analog Output |
4-20 mA / DC / 0-20 mA DC |
|
Communication port (Optional) |
RS 232 / RS 485 MODBUS RTU protocol |
|
Response time |
5 Second |
|
Flow velocity Range |
0.3 to 10 m/s |
|
Ingress Protection |
IP 65 ( IP 68 on request) |
|
LED Display |
4 Digit Indication for flow rate and 8 digit indication for Totaliser programming from keyboard for engineering unit |
|
Accuracy |
K 0.5 % of measured value (calibrated) at reference conditions |
SALIENT FEATURES:-
- Based on faradays law of Electromagnetic Induction
- Suitable for pipe sizes of diameters 10 mm to 600mm
- Coil Assembly in hermetically sealed welded construction
- Choice of PTFE / Neoprene rubber / Polyurethane liners
- Integral orremote transmitter
- Field Interchangeable electronics
- Optional LED display for flow rate or Totaliser indication in engineering units.
- No pressure loss
- Absolute zero stability and noise elimination.
- Measurement independent of liquid properties.
- Display of flow rate directly in user specified engineering units
- Negligible pressure loss
- Maintenance free design due to absence of any moving parts
Rugged Design for Demanding Conditions
Constructed with powder-coated aluminium enclosure, the electromagnetic flowmeter achieves a protection class of IP65 and offers IP68 as an optional upgrade. This ensures safe operation in environments where dust and water exposure are considerations, making it suitable for outdoor or industrial installations across varied climatic conditions.
Versatile Mounting and Fluid Compatibility
This flowmeter features flanged mounting as per ANSI B16.5, DIN, or JIS standards, and comes equipped with PTFE or Hard Rubber lining options. Electrode materials such as SS316L, Hastelloy C, or Titanium enhance durability and compatibility with both aggressive and neutral fluids, supporting a broad range of process applications.
Advanced Data Output and Communication
Equipped with multiple signal output options4-20 mA, pulse output, and RS485this flowmeter facilitates seamless integration into your process control systems. With optional Modbus and HART communication protocols, data transmission is both flexible and secure for remote monitoring or centralized data acquisition.
FAQs of Electromagnetic Flowmeter:
Q: How is the electromagnetic flowmeter installed in a pipeline system?
A: The flowmeter is designed for flanged mounting according to ANSI B16.5, DIN, or JIS standards. It should be installed inline with the process piping, ensuring correct alignment and orientation for optimal performance across pipe diameters ranging from DN15 to DN600.Q: What types of fluids are compatible with this flowmeter?
A: Thanks to its PTFE or Hard Rubber lining and choice of SS316L, Hastelloy C, or Titanium electrodes, the flowmeter is compatible with a wide spectrum of conductive process fluids, including aggressive chemicals, water, and other industrial liquids.Q: When should the optional IP68 protection class be selected?
A: IP68 protection is recommended for applications involving continuous immersion in water or exposure to extremely wet environments. This option provides enhanced waterproofing, ensuring that the device remains reliable even under challenging site conditions.Q: What output signals and communication protocols does the flowmeter support?
A: The device offers 4-20 mA, pulse, and RS485 outputs as standard. Additionally, optional Modbus and HART protocols are available, allowing easy connection to industrial control and monitoring systems for efficient data communication and process integration.Q: How does EEPROM-based memory retention benefit users?
A: EEPROM memory ensures that all important measurement data and settings are safely retained during power failures, safeguarding against data loss and reducing the need for manual reconfiguration after an outage.Q: Where can this electromagnetic flowmeter be deployed?
A: It is suitable for a wide range of industrial applications, including water treatment plants, chemical processing, food and beverage industries, and any installation requiring reliable and accurate flow measurement of conductive liquids.Q: What is the measurement accuracy and repeatability of the instrument?
A: The flowmeter offers high measurement accuracy of 0.5% of reading and a repeatability of 0.2%, ensuring consistent and precise flow readings across its specified measuring range.Tell us about your requirement
